Refrigerator truck (also called refrigerator wagon, refrigerated truck, refrigerated boxcar, freezer vehicle, freezer wagon, temperature controlled truck, refrigerator car, preservation vehicle) is used to carry perishable stuff at specific temperatures.
The cooling device could be of famous brand such as Carrier, Thermoking……
There are two types of power driving ways - one is powered by vehicle engine through PTO, the other is driven by a separately carried power unit.
According to the transport stuff category (fresh or frozen), there are two main lowest temperature unit (-5°and -16°) for your option.
We use high quality van body for temperature reservation. The box surface material could be fiberglass,aluminum or stainless steel. The padding material is polyurethane foam that has super temperature preservation ability with varieties of thickness options.
---- SINOTRUK chassis ensures perfect driving performance.
---- SINOTRUK engine, super powerful; reliable performance.
---- Nice shape, rational structure
---- High quality temperature preservation van body
---- Excellent Chinese brand temperature controlled unit or imported cooling system
---- Massive, durable, perfect performance
---- Prolonged service life
Refrigerator Truck SINOTRUK ( 10 Ton ) | ||
General | Vehicle Brand | SPV |
Chassis Brand | SINOTRUK | |
Overall Dimension | 8940 * 2580 * 3920 mm | |
GVW / Kerb Weight | 16,000 kg / 8,900 kg | |
Cab | Cab Capacity | 2 persons allowed with 1 sleeper |
Air Conditioner | Air conditioner is equipped | |
Engine | Fuel Type | Diesel |
Engine Brand | SINOTRUK engine | |
Power | 266 Hp (213 KW) | |
Displacement | 9726 ml | |
Emission Standard | Euro II | |
Chassis | Drive Type | 4X2, left hand drive or right hand drive |
Transmission | 10-speed forward, 2 reverse | |
No. of axle | 2 | |
Tyre Specification | 12R22.5, Radial tyres, super wearable | |
Tyre Number | 6 tyres and 1 spare tyre | |
Max Speed | 95 km/h | |
Paint | Metallic paint | |
Superstructure | Box Capacity | 10 Ton |
Box Internal Dimension | 5800 * 2400 * 2400 mm | |
Box Material | Fiberglass with 80 mm foaming | |
Doors | Two rear doors fully openable and one side door | |
Bottom Floor | Aluminium alloy checked plate(anti-slip) with aluminium ventilation stripes | |
Cooling system | American brand: Thermo King | |
Lowest temperature | -5° | |
Accessories | Stainless steel locking and hinge | |
All other standard accessories: Tool kit, English manual…… | ||
Optional |
** Box material could be aluminum or stainless steel. ** Cooling system could be imported brand. ** Temperature data logger, temperature alarm. ** Extra side door. ** Slide rail and meat hook for special use. |
