ShangHai SPV Special Vehicle Co., Ltd.
Galvanized dustbin (also called waste bin, garbage bin, dustbin, garbage trolley, plastic waste bin, steel dustbin, out door wastbin, etc) is used to collect garbage from buildings, houses, farm, park, street, etc.
It could be made of plastic, steel, aluminium, stainless steel, etc.
The capacity could be: 120 L, 240 L, 660L, 1100 L, etc.
EN-840 standard or customized according to special requirements.
| Garbage Trolley ( 1100 L) | ||
| General | Brand | SPV |
| Model | SPV - 1100 L - 1 | |
| Overall Dimension | 1450 * 1380 * 1020 mm | |
| Material | Hot dip galvanized steel | |
| Standard | EN 840 | |
| Kerb Weight | 125 kg ± 5% | |
| Container Thickness | Body | 1.5 mm |
| Cover | 1.25 mm | |
| Lid Arm | 3.00 mm | |
| Wheel Base | 4.00 mm | |
| Tolerance | ± 0.3 mm | |
| Wheels | No. of Wheels | 4 |
| Type | Heavy-duty solid wheels | |
| Diameter | 200 mm | |
| Rotation | 360 ° | |
| Drainage Hole | At the bottom of the container for drainage and cleaning. | |
| The cover welded by CO2 and the arms will be assembled to the cover by screws. | ||
| The cover supplied with rubber strap to protect the hands of users. | ||
| The cover has three stages of movements for opening and closing. | ||
| Optional | ** Container material: steel, plastic, aluminium, stainless steel, etc. | |
