ShangHai SPV Special Vehicle Co., Ltd.
Road wrecker (also called tow truck, breakdown truck, recovery truck, breakdown lorry, wrecker, police rescue truck, flatbed tow truck, boom truck, wheel-lift wrecker ) is used to transport motor vehicles or the vehicles that are broken down.
Based on the type or size of vehicle to be towed, wreckers are usually designed into two types. One is slidebed tow truck with wheel-lift function; another one is wheel-lift units that offer a combination boom with sling.
---- ISUZU chassis, perfect performance.
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure
---- High quality hydraulic system
---- Massive, durable, perfect performance
---- Prolonged service life
Similar Key Words: ISUZU road wrecker, tow truck, police rescue truck, breakdown truck, recovery truck, breakdown lorry, flatbed tow truck, boom truck, wheel-lift wrecker, heavy recovery vehicle
| Road Wrecker Truck ISUZU ( Towing and Lifting type ) | ||
| General | Vehicle Brand | SPV |
| Chassis Brand | ISUZU | |
| Overall Dimension | 7450 * 2330 * 2520 mm | |
| GVW / Kerb Weight | 5,495 kg / 4,165 kg | |
| Cab | Cab Capacity | 2 persons allowed |
| Air Conditioner | W/ air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU engine, 4HK1 | |
| Power | 120 Hp (88 KW) | |
| Displacement | 2999 ml | |
| Emission Standard | Euro IV | |
| Chassis | Drive Type | 4X2, left hand drive |
| Transmission | ISUZU gear box, no overhaul within 500,000km | |
| Wheelbase/No. of axle | 3360 mm / 2 | |
| Tyre Specification | 7.00-16 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 100 km/h | |
| Paint | Metallic paint | |
| Superstructure | Towing Type | Wheel-lift conbined with towing boom |
| Wheel-lift Capacity | 3 Ton | |
| Towing Winch Capacity | 4 Ton | |
| Steel Rope Length | 25 M | |
| "L" Bracket | 1 set (let and right) | |
| All other standard accessories: tool box, binding belt, auxiliary sliding board, tool kit, English operation manual…… | ||
| Optional | ** LED alarm lamp is optional. | |
Photo 3: Right front view of ISUZU road wrecker truck ( towing and lifting type)
Photo 4: Right side view of ISUZU road wrecker truck ( towing and lifting type)
Photo 5: Right back view of ISUZU road wrecker truck ( towing and lifting type)
