Water Spraying Truck Sinotruk(RHD)
20,000 Litres Water Tanker Truck
Water Spraying Truck Sinotruk(RHD)
Function:

Water spraying truck (also called water tanker truck, water sprinkling truck, mobile water truck, watering truck, water bowser, water truck tanker, water carrying truck, water tank for truck, water distribution truck) is used to transport and supply water, whatever industrial or agriculture water, widely used in construction engineering, farm irrigation, draught relief, etc.

With non-toxic treatment inside tank or tank made of stainless steel, the water tank truck can be suitable for transporting drinking water, called as potable water tanker, drinking water tanker, stainless steel water tanker, agua potavel, safe to human body.

Water tanker can also be equipped with special sprayers to achieve front flush, rear sprinkle, side spray, to sprinkle and clean the roads, streeets for environmental sanitation and protection, called as water sprinkler, water spray truck.
With rear working platform and high cannon, the Water lorry can also be used to water the plants, even high trees in virescence, called as watering truck.

Water bowser can be also equipped with pesticide spraying machine, to be used to spray pesticide in agriculture pest control field.

Features:

---- Sinotruk engine, super powerful; reliable performance.
---- Nice shape, rational structure
---- Water pump super powerful, efficient pump in and out
---- Strong, durable, perfect performance
---- Prolonged service life



Specification:

Water Spraying Truck Sinotruk (Right Hand Drive)
General Vehicle Brand SPV
Chassis Brand Sinotruk
Overall Dimension 8800 * 2500 * 3200 mm
GVW / Kerb Weight 25,000 kg / 13,800 kg
Cab Cab Capacity 2 persons allowed with 1 sleeper
Air Conditioner Air conditioner is equipped
Engine Fuel Type Diesel
Engine Brand Sinotruk engine
Power 371 Hp (272 KW)
Displacement 9726 ml
Emission Standard Euro II
Chassis Drive Type 6X4, Right Hand Drive
Transmission 10-speed forward, 2 reverse
Wheelbase/No. of axle 3
Tyre Specification 10.00-20
Tyre Number 6 tyres and 1 spare tyre
Max Speed 90 km/h
Paint Metallic paint
Superstructure Tank Capacity 20,000 Litres ( About 5,300 gallons)
Tank Material Carbon steel
Flow Speed 1000 litres / min
Delivery Head 90 m
Suction Head 6 m
Optional ** Tank material could be stainless steel or carbon steel with non-toxic treatment for potable water, safe for human body.

Similar Key Words: watering truck, water bower, irrigation water tank, water tanker transport truck, clean water bowser, water truck for dust control, water tanker

Water Spraying Truck Sinotruk - F
Photo 1: Front view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD

Water Spraying Truck Sinotruk - LS
Photo 2: Left side view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD

Water Spraying Truck Sinotruk - LB
Photo 3: Left back view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD

Water Spraying Truck Sinotruk - RF
Photo 4: Right front view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD

Water Spraying Truck Sinotruk - RS
Photo 5: Right side view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD


Water Spraying Truck Sinotruk - RB
Photo 6: Right back view of Water Spraying Truck Sinotruk(20,000 Litres) - RHD

Water Spraying Truck Sinotruk - Front Flushing - 1
Photo 7: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - front flushing

Water Spraying Truck Sinotruk - Side Spraying
Photo 8: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - Side Sprinkling

Water Spraying Truck Sinotruk - Rear Spraying
Photo 9: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - Rear Spraying

Water Spraying Truck Sinotruk - Rear Spraying Testing
Photo 10: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - Rear Spraying Testing

Water Spraying Truck Sinotruk - Water Cannon Shooting
Photo 11: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - Water Cannon Shooting

Water Spraying Truck Sinotruk - Detail
Photo 12: Water Spraying Truck Sinotruk(20,000 Litres) - RHD - Manual and Truck Plate
